Product Details:
Payment & Shipping Terms:
|
| Material: | PVC + Polyester | Color: | Orange Or Customized |
|---|---|---|---|
| Technics: | Woven | Thickness: | 0.47-0.7mm |
| Application: | Agriculture Or Industry | Logo: | Available |
| Packing: | By Roll | Feature: | Anti-Abrasion |
| High Light: | High Pressure PVC Layflat Hose,Flexible PVC Layflat Hose,Agriculture Irrigation 2 Inch Layflat Hose |
||
High Pressure 2 Inch Pvc Soft Hose Flexible Layflat Agriculture Irrigation
| Product name | Flexible Pvc Layflat Hose |
| Application | Agriculture and forestry irrigation,Industrial field etc. |
| Feature | One-time extrusion molding. Thin wall, light weight, high pressure. Acid and alkali resistance, anti-aging. Environmental protection grade hose can pass REACH testing standards. |
| Size | I.D.:1-8 inch 50M/Roll Can produce up to 100 meters |
| I.D.:2-8 inch 20M/Roll Can produce up to 100 meters | |
| Delivery time | 10 days / 10000 meters15 days / 35000 meters 20 days / 60000 meters |
| Payment terms | 1. T/T 30% advance payment, 70% balance against B/L copy. 2. L/C |
Specification of pvc sofe hose/layflat pipe
| S/N | MODEL | INCH | I.Dmm | THICKNESS cmm |
Length M/ROLL |
Package | MAX.W.P Bar At23℃ | kg/Weight |
| 1 | JLYA-A2.0 | 2" | 50 | 70 | 50 | 2 | 8.5 | 9 |
| 2 | JLYA-A2.5 | 2.5" | 65 | 70 | 50 | 2 | 8.2 | 10.8 |
| 3 | JLYA-A03 | 3" | 80 | 70 | 50 | 1 | 8.0 | 12.6 |
| 4 | JLYA-A04 | 4" | 100 | 70 | 50 | 1 | 6.0 | 16.2 |
| 5 | JLYA-A06 | 6" | 150 | 70 | 50 | 1 | 4.0 | 23.4 |
| 6 | JLYA-A08 | 8" | 200 | 70 | 50 | 1 | 3.0 | 30.6 |
| 7 | JLYA-B1.0 | 1 | 25 | 47 | 100 | 3 | 7.0 | 7.2 |
| 8 | JLYA-B1.5 | 1.5 | 40 | 47 | 100 | 3 | 6.5 | 9.6 |
| 9 | JLYA-B2.0 | 2" | 50 | 47 | 20/50/100 | 2 | 6.0 | 2.4/6.0/12.0 |
| 10 | JLYA-B2.5 | 2.5" | 65 | 47 | 20/50/100 | 2 | 5.8 | 2.9/7.2/14.4 |
| 11 | JLYA-B03 | 3" | 80 | 47 | 20/50/100 | 1 | 5.5 | 3.4/8.4/16.8 |
| 12 | JLYA-B04 | 4" | 100 | 47 | 20/50/100 | 1 | 4.2 | 4.3/10.8/21.6 |
| 13 | JLYA-B06 | 6" | 150 | 47 | 20/50/100 | 1 | 3.0 | 6.3/15.6/31.2 |
| 14 | JLYA-B08 | 8" | 200 | 47 | 20/50/100 | 1 | 2.0 | 8.2/20.4/40.8 |
