950gsm PVC Collapsible Water Storage Tank Easy Fold Huge Capacity

950gsm PVC Collapsible Water Storage Tank Easy Fold Huge Capacity
950gsm PVC Collapsible Water Storage Tank Easy Fold Huge Capacity 950gsm PVC Collapsible Water Storage Tank Easy Fold Huge Capacity 950gsm PVC Collapsible Water Storage Tank Easy Fold Huge Capacity 950gsm PVC Collapsible Water Storage Tank Easy Fold Huge Capacity

Large Image :  950gsm PVC Collapsible Water Storage Tank Easy Fold Huge Capacity

Product Details:
Place of Origin: China
Brand Name: JLM
Certification: CE,BV,SGS,ISO9001
Model Number: JLM-301
Payment & Shipping Terms:
Minimum Order Quantity: 100piece
Price: Negotiable
Packaging Details: Pvc bag
Delivery Time: 35 working days after received your payment
Payment Terms: T/T
Supply Ability: 10000 piece per month
Detailed Product Description
Durability: 5 Years Function: Tear-Resistant
Color: Blue,yellow,customized Temperature: -30℃-70℃
Application: Water Storage/Drinking/Fire Fighting,water Supply For Industry After-sales Service Provided: Online Support
Shape: Rectangular/square/round/onion Material: PVC+polyester
High Light:

pillow water tank

,

collapsible water storage tank

950gsm PVC Collapsible Water Storage Tank Easy Fold Huge Capacity



Description:



Inflatable PVC tarpaulin is a vinyl coated fabric that stands out due to its durability and long life. It’s an ideal choice for outdoor advertising, big tents, pavilions, semi-permanent structures, storage tents etc. This vinyl coated tarpaulin is produced in accordance with our highest quality standard. It can be treated with flame retardant, surface lacquering, resistant to heat and cold.





Feature:

1) 100% high tenacity polyester yarns with PVC coating;

2) Laminated technology & Hot-melt Coating technology;

3) Good strength, good flexibility, and adhesion strength;

4) Outstanding tearing strength for welding;

5) Cold Crack Resistance, Anti-Mildew, Anti-Static treatment, Waterproof;

6) Anti ultraviolet treatment(UV)(optional);

7) Acrylic treatment (optional).



Applications:



• Temporary Storage

• Rainfall Collection

• Residential and Public Storage of Water

• Defense Water Storage Applications

• Emergency Storage and Relief

• Irrigation

• Choose PVC water tank to test bridge maximum load

• Fire fighting in forest



Specification:

Capacity
( m^3)

Empty size
(m)

Full height
(m)

Net weight
(kg)

Folding size
(m)
1 2.2*1.9 0.4 14 0.7*0.65*0.2
5 3.8*3.2 0.6 50 1.0*0.8*0.75
10 4.5*4.4 0.8 85 0.9*0.75*0.4
50 8.5*7.0 1.1 220 1.5*0.9*0.65
100 11.0*9.5 1.2 390 1.5*1.1*0.7
200 16.6*9.5 1.6 630 2.0*1.1*0.9
400 17.2*15.7 1.7 1050 4.25*1.1*0.7
800 22.5*23 1.7 1720 5.7*2.1*0.7



Quick Detail:

1. light weight, easy operation.

2. minimum packing size, easy for transportation and storage.

3. no contamination for water, which may guarantee the quality of the material.

4. high strength of the coated fabric

5. high strength of the seams because of the high frequency melt and sealed with the same polyurethane as the tank body, so the tanks have excellent ability against air leakage and it's very safe for water.

6. The houses can be easily assembled and disassembled for several times without damage, not bring out building debris.



Technological process:

1. Base fabric high tenacity polyester

2. Coating flexible plasticized PVC with UV inhibitors

3. Polymer fabric with PVC coating clipped

4. High-frequency welding or heat sealing



Storage capacity, temperature:

1. Capacity(liter): 200~100000

2. Temperature(° C): -30~+70

3. Remarks: We are the factory. And we can manufacture water tank of any capacity, any colour, any size according to your requirements.

4. we can accept OEM order.
